Winton WTM140 1.4m Tractor Topper Mower
Tractor Topper Mower with Adjustable Skids for Overgrown Areas
The Winton WTM140 Topper Mower expertly tops grass and weeds in overgrown areas, offering rotary cutting action with adjustable skids for height control.
cheaper?
We can also take orders over the phone, or help with BACS payments.
Overview
The Winton WTM140 at a glance
Mower Type
Topper Mower
Tractor HP
23 - 40 hp
Mower Position
Manual Sideshift
Cutting Width
140 cm
Cutting Height
50 - 250 mm
Weight
205 kg
Free PTO Shaft
Included
Free Delivery
Included
Description
Why buy the Winton WTM140 1.4m Tractor Topper Mower?
Our topper mower WTM140 is ideal for overgrown pasture and paddock areas. It’s the perfect mower for ‘topping’ a variety of grasses, brambles, light scrub and saplings. This topper can be used on smallholdings on areas with grazing horses, sheep or alpacas.
The machine uses rotary style cutting action with 2 blades, one on each end of the blade carrier. This creates the ‘topping’ action when mowing. The cuttings are often longer than other mower types and collect in rows along the skids.
Fully adjustable skids for flexible cutting height, adjustment can be made by simply unbolting the side skids. It is also fitted with a stone guard for extra peace of mind when cutting.
The implement can be attached to the 3 point linkage of a range of small or compact tractors.
A PTO drive shaft with shear bolt protection is included with the mower.
Features:
• Height adjustable skids
• Rear safety stone guard
• 5-25cm cutting height range
• Category 1 size linkage
IMPORTANT: Item requires unloading facilities when shipped via pallet. Please contact us for alternative delivery arrangements if you do not have access to a forklift etc.
---
Optional Winton WTM topper mower service pack:
• 2x blades
• 1x 1L bottle of gear oil
• 1x grease cartridge
• 2x blade bolts & nuts
Specifications
Dive into the details for the WTM140
Brand
Winton Machinery
Reference (SKU)
WTM140
Weight
205kg
Dimensions
155cm x 165cm x 100cm
Tractor HP Required
23-40HP
Cutting Heights
5-25cm
Working Width
140cm
Lower Linkage Width
45-70cm
Linkage Type
Cat 1
Oil Type
Gear Oil 80W90
Warranty
12 months manufacturer's warranty
Which Cutting Width to Choose? Compare Models Below
Enter your tractor's horsepower or the make & model to see which models fit.
Compatibility assumes a standard PTO speed of 540RPM clockwise, a Type 1 / 2 linkage, and hydraulic spools where necessary.
Verified Winton WTM Reviews
Collected from Tried & Tested Customers
Easy ordering and really good delivery
Easy ordering and really good delivery
Model:
WTM140
The Winton topper mower is quite good and leaves a tidy finish
The Winton topper mower is quite good and leaves a tidy finish. It is also good for mowing bracken and brambles and even small saplings up to 12mm /18mm thick.
Model:
WTM140
Very well constructed. The topper deals with grass clumps and rushes very effectively. I had an initial problem connecting the pto shaft to the tractor (an old Kubota) but that turned out to be due to an old and much welded towing bracket. Once removed all was well. Thanks
Very well constructed. The topper deals with grass clumps and rushes very effectively. I had an initial problem connecting the pto shaft to the tractor (an old Kubota) but that turned out to be due to an old and much welded towing bracket. Once removed all was well. Thanks
Very satisfied
All good as delivered on time and looks like a solid machine
Winton WTM140 FAQs:
The most commonly asked WTM140 questions. If your questions is not here, please contact us.
