Kubota B9200 Specifications

Production

Who manufactured the Kubota B9200 and what are its variants?

• Manufacturer: Kubota
• Variants:
  • B9200F: 2WD gear
  • B9200DT: 4WD gear
  • B9200HSE: 2WD hydro
  • B9200HSD: 4WD hydro
  • B9200HST: hydrostatic transmission

Engine

What type of engine does the Kubota B9200 have?

• Type: Kubota 1.2L 4-cyl diesel

Transmissions

What are the transmission options for the Kubota B9200?

• 9-speed
• hydrostatic

Horsepower

What is the horsepower of the Kubota B9200?

• Engine (gross): 22.5 hp (16.8 kW)
• PTO (claimed): 16 hp (11.9 kW)

Mechanical

What are the mechanical specifications of the Kubota B9200?

• Drive: 4x2 2WD, 4x4 MFWD 4WD (optional)
• Steering: hydrostatic power
• Brakes: dry internal expanding brakes
• ROPS: two-post

Capacity

What is the fuel and hydraulic system capacity of the Kubota B9200?

• Fuel: 5.3 gal (20.1 L)
• Hydraulic system: 4.75 gal (18.0 L)

Hydraulics

What are the hydraulic specifications of the Kubota B9200?

• Type: open center
• Capacity: 4.75 gal (18.0 L)
• Pressure: 1930 psi (133.1 bar)
• Valves: 1
• Total flow: 7.1 gpm (26.9 lpm)

Tractor hitch

What are the tractor hitch specifications of the Kubota B9200?

• Rear Type: I
• Rear lift (at ends): 1,279 lbs (580 kg)
• Rear lift (at 24"/610mm): 1,014 lbs (459 kg)

Power Take-off (PTO)

What are the PTO specifications for the Kubota B9200?

• Rear PTO: live
• Rear RPM: 540/748
• Mid RPM: 1847/2557

Dimensions & Tires

What are the dimensions and tire specifications of the Kubota B9200?

• Wheelbase: 62 inches (157 cm)
• Weight: 1570 to 1676 pounds
• Front tire: 6.50-10
• Rear tire: 12.4-16
